 Expert in Water Quality Measurement and Water Treatment Project Since 2007

BOQU quality pressure transducer directly sale for liquids 1
BOQU quality pressure transducer directly sale for liquids 1

BOQU quality pressure transducer directly sale for liquids

Model:
BQA100H
Mob/WhatsApp:
OEM, ODM, Customized
Place of Origin:
China Shanghai
DeliveryTime:
7-10 working days
MOQ:
1 PCS per item
Inquiry
Application Scope
BOQU Instrument's water quality sensor can be used in multiple scenes.BOQU Instrument always focuses on meeting customers' needs. We are dedicated to providing customers with comprehensive and quality solutions.
  • BOQU quality pressure transducer directly sale for liquids 2
Enterprise Strength
  • BOQU Instrument has a professional customer service team to supply free technical advice and guidance.
Company Advantages
1. The design of BOQU water pressure transducer is thoughtful, accurate, and delicate, combining aesthetic look and functionality.
2. This product has obtained international quality certificates such as ISO9001.
3. Shanghai Boqu Instrument Co., Ltd.'s pressure transducer products are recognized and praised at home and abroad.
4. The good quality pressure transducer has helped BOQU to win many customers.

Company Features
1. It is of great significance to improve pressure transducer for the development of BOQU.
2. The factory is equipped with many international level quality testing facilities. We require all products must be 100% tested under these testing machines to ensure their functionality, reliability, security, and durability before shipment.
3. We are constantly improving the quality of pressure sensor in order to seek better development. Call! Shanghai Boqu Instrument Co., Ltd. is committed to improving the positioning and fairness of BOQU. Call! More new projects are being developed by Shanghai Boqu Instrument Co., Ltd. to expand more markets. Call! Shanghai Boqu Instrument Co., Ltd. wants industrious and creative people to grow with us. Call!

Low differential pressure transducer  0-50Pa 150Pa 1KPa 10KPa 100KPa -500Pa-500Pa



YGX-PTS802



Features & Applications:

Micro differential pressure sensor silicon piezoresistive differential pressure core and refined, shell of aluminium alloy or stainless steel structure. Two pressure interface for the M10 screw and plug structure, can be installed directly in the measuring pipe line or by pressured tube connecting.



Widely used in boiler fan, ventilation in the pit and other electric power, coal industry and paint, beverages and other liquid beverage bottles, cans packaging leakage detecting pressure process control field.



Range:   0~ 50Pa~ 150Pa ~1KPa~ 10KPa ~100KPa, -500Pa ~500Pa



Technical parameters:

Range

0~ 50Pa~ 150Pa ~1KPa~ 10KPa ~100KPa,

-500Pa ~500Pa

High pressure three times the range values
Comprehensive accuracy 0.5%FS, 1.0%FS
Output signal

4~ 20mA ( two wire system ), 0~5V, 1~5V,

0~10V ( three wire system )

Power supply voltage24DCV ( 9 ~ 36DCV)
Medium temperature  -20 °C ~ 85 °C
Environment temperatureroom temperature ( -20 ~ 85°C)
Load resistance

current output type: maximum 800 Ω;

voltage output type: larger than 50KΩ

Insulation resistancelarger than 2000MΩ ( 100VDC)
Sealed classIP65
Long term stability  0.1%FS/year
Influence of vibration

within mechanical vibration frequency: 20Hz ~ 1000Hz,

output variation is less than 0.1%FS

Electrical interface

two core wire

Mechanical connection

( thread interface )

M10 ×1 connect Φ 8 pipe joint,

custom made is available.



YGX-PTS802    Product    picture





Dimensions:







Custom made is available.

We can produce the products according your requirements.



FAQ:



1. What is the MOQ?

 If we don’t have it in stock, the MOQ is 5 pcs

If we have it in stock, we can ship you even 1 pc as sample.



2. What is lead time?

If we have it in stock, we can ship it to you within about 3-5 working days.

If we don’t have it in stock, the lead time will be 10-30 days.



3. What is the payment terms?

T/T, Western Union, L/C, Escrow alibaba  is acceptable.

Escrow is same like paypal, after you place the order and make the payment on alibaba.com, alibaba company will notify us to make the shipment, your money won’t be released until you get the goods.

If we don’t make the shipment, you still can take back your money.



4. What is the express delivery?

DHL, Fedex, TNT ,EMS, UPS etc.

We will choose the safe and cheapest way for you to reduce your cost.

Economic shipping way: by sea, by air transport

If you place mass order with us, the shipping way of by sea or by air transport will be ideal choice.



5. What is the quality guarantee?

Quality guarantee:  12 months.

If the product has quality problem within 12 months, please return it to us, we will repair it; if we can’t repair it successfully, we will give you a new one; but the man-made damage, improper operation and force majeure will be excepted.

And you will pay the shipping cost of returning to us, we will pay the shipping cost to you.



6. Is there any after-sale service?

 After you receive our product, if you have any questions or need any assistance, we can provide you the after-sale service by e-mail,skype,trade manager,telephone and QQ etc.



7. How to contact us?

Tel: +86 755 28912958

Skype: yuanguigen

Trade manager: szygx

QQ: 1225609859

E-mail: ygxtechgmail.com
