Online Nitrate Nitrogen Analyzer
NNA-210 ONLINE NITRAGE NITROGEN ANALYZER
Measuring Principle
NO3-N will be absorbed at 210 nm UV light. When the Spectrometer Nitrate NIitrogen sensor is working, the water sample flows through the slit. When the light from the light source in the sensor passes through the slit, part of the light is absorbed by the sample flowing in the slit, and the other light passes through the sample and reaches the other side of the sensor. Calculate the concentration of nitrate.
Application
1)Drinking water / surface water
2)Industrial production process water / sewage treatment, etc.,
3)Continuously monitor the concentration of nitrate dissolved in water, especially for monitoring sewage aeration tanks, controlling denitrification process
TECHNICAL PARAMETERS
| Product | NNA-210 Online Nitrate Nitrogen Meter |
Measuring range | Nitrate nitrogen, NO3-N: 0.1~50.0mg/L( 2mm ) |
Accuracy | Accuracy: ±5% |
| Repeatability | ± 2% |
| Resolution | 0.01 mg/L |
| Pressure range | ≤0.4Mpa |
| Sensor material | Body:SUS316L(freshwater),Titanium alloy(sea water) |
Communication | RS485 Modbus RTU |
Power | AC:85-500VAC (50/60HZ) ;DC:9~36VDC |
| Output | 2 ways of 4-20mA |
| Communication | RS485 Modbus RTU |
| Relays | 3 ways of relay |
| Working temperature | -15 to 60℃ |
Protection | Nitrate Nitrogen transmitter IP65, Nitrate Nitrogen Sensor IP68 |
| Length of Cable | Standard 10-meter long cable, which can be extended to 100 meters |
MAIN FEATURES
